Rockwell Hardness Testers / Testing Machines

We are Manufacturer, Supplier, Exporter of Rockwell Hardness Testers, Rockwell Hardness Testing Machines, Material Testing Machines, Metal Testing Equipments, Universal Testing Machines, UTM Machines from Kolhapur, Maharashtra, India.

Technical Data : Rockwell Hardness
MODEL UNIT RAS RASM RAB-1 RAB-250 TWIN
Load kgf. 60, 100, 150 60, 100, 150 60, 100, 150, 187, 5250 60, 100, 150, 187, 5250 15, 30, 45 (Rockwell Superficial) 60, 100, 150(Rockwell)
Initial Load kgf. 10 10 10 10 3(Rockwell Superficial) 10 (Rockwell)
Max. test Height mm. 230 230 230 330 330
Depth of throat mm. 133 133 133 133 150
Max. dept of elevating screw below base mm. 240 240 240 355 355
Size of base (Approx) mm. 170 X 430 170 X 430 170 X 430 210 X 474 210 X 474
Machine Height (Approx) mm. 655 655 655 850 850
Nett Weight (Approx) kg. 65 65 65 100 100
